The Polaris Intruder-Resistant (IR) is a heavy-duty roller shutter that is the ultimate in design for visual appearance and maximum security. Whilst visually attractive, robust, and effective, the Polaris (IR) Doors are made with a precision extruded roller shutter profile, suitable for many high-security commercial and industrial-grade applications.
POLARIS IR INTRUDER-RESISTANT ALUMINIUM ROLLER SHUTTER
Technical Specifications
MAXIMUM WIDTH: 7000mm (Motorised)
MAXIMUM HEIGHT: 4000mm (Motorised)
APPROX. WEIGHT PER SQM: 18 kgs. per sqm
SLAT HEIGHT: 50mm
SLAT THICKNESS: 1.6mm (double wall)
BARREL TYPES: 150mm steel
BRACKETS: 6mm mild steel angles and plate
SIDE GUIDES: 82mm deep x 29mm wide (face fixed or heal fixed)
WIND LOCKS: Yes
DOOR FINISH: Standard Satin Silver Anodised / Dulux Duralloy Powder Coating
Product Specification Sheet
Product warranty—12 months (Materials and Workmanship)
Scotty Doors Ltd has a continuing programme of product development and reserves the right to alter specifications at any time without notice.
Door Operation
- Motorised operation (low cycle applications only – not available in high cycle applications) via a single-phase motor / controllers / limit switches
Power Requirements (for Motorised Operation)
- Single-phase outlet (10amp), located within 1 metre of the motor—plug and go setup
- Three-phase 415V with neutral (10amp), located within 1 metre of the motor, to be fully installed & connected by a certified electrician
Motorised (Single Phase)
- Head Room: 550mm
- Side Rooms: Motor Side: 160mm / Non-Motor Side: 120mm
- Projection: 750mm
Motorised (Three Phase)
- Head Room: 550mm
- Side Rooms: Motor Side: 400mm / Non-Motor Side: 150mm
- Projection: 750mm
External Work by Others
- Power supply provision, if required
- Structurally sound wall/mounting points to support the roller grille, designed & approved a certified engineer
- Adequate headroom, side room, and projection to ensure successful operation
